CU/XLPE/CWS/PVC 12/20KV 3-CORE -IEC
CU/XLPE/CWS/PVC 12/20KV 3-CORE -IEC
Unarmoured 3-core XLPE insulated MV cable. Rated voltage 12/20 (24) KV
Read moreCU/XLPE/CWS/PVC 20KV 3X 35/16
Nexans ref. 13006096 - Country ref. 13006096
- Packaging: Cut to length (m)
CU/XLPE/CWS/PVC 20KV 3X 50/16
Nexans ref. 13002942 - Country ref. 13002942
- Packaging: Cut to length (m)
CU/XLPE/CWS/PVC 20KV 3X 70/16
Nexans ref. 13003788 - Country ref. 13003788
- Packaging: Cut to length (m)
CU/XLPE/CWS/PVC 20KV 3X 95/16
Nexans ref. 13003530 - Country ref. 13003530
- Packaging: Cut to length (m)
CU/XLPE/CWS/PVC 20KV 3X120/16
Nexans ref. 13002660 - Country ref. 13002660
- Packaging: Cut to length (m)
CU/XLPE/CWS/PVC 20KV 3X150/25
Nexans ref. 13004880 - Country ref. 13004880
- Packaging: Cut to length (m)
CU/XLPE/CWS/PVC 20KV 3X185/25
Nexans ref. 13006097 - Country ref. 13006097
- Packaging: Cut to length (m)
CU/XLPE/CWS/PVC 20KV 3X240/25
Nexans ref. 13006098 - Country ref. 13006098
- Packaging: Cut to length (m)
CU/XLPE/CWS/PVC 20KV 3X300/25
Nexans ref. 13001060 - Country ref. 13001060
- Packaging: Cut to length (m)
Description
Description
Standards
-
ProductIEC 60502-2
Application
MV 3-core cable suitable for outdoor and indoor installation, in air, in grounds, in cable ducts.
The cable is suitable for rated voltage 12,7/22KV (Um=24KV) according to BS standards
Construction
MV 3-core cable is consisted of stranded (class 2) copper conductors, semiconductive conductor screen, XLPE insulation, semiconductive insulation screen, copper wires metallic screen on each core, PVC outer sheath.
